VEHICLE CONSTRUCTION
High-quality production of individual vehicles
Our vehicle construction department in Herten has decades of experience in the manufacture of tank semi-trailers (TSA) , tank trailers and container chassis.
Chemical tank semi-trailer
Jumbo tank semi-trailer
Food tanker semi-trailer
Tank trailer
Container chassis
Our tank semi-trailers
We specialize in the manufacture of stainless steel tank (semi-trailer) trailers for the transport of hazardous goods with a tank volume of 10 m³ (tank trailer) to 56 m³ (jumbo TSA). All structural elements in contact with the tank are made of stainless steel.
Individual vehicle construction
We equip our vehicles according to your wishes. Chamber sizes anddivisions can be defined within the scope of our prototypes according to your specifications. Different types of heating are also possible, such as insulation with mineral fiber mats, solid insulation or combinations thereof.
Equipment of our tank semi-trailers / tank trailers
-
Vehicle volume
Vehicle volume from 10 m³ (tank trailer) to 56 m³ (jumbo tank semi-trailer)
-
Insulation
Combination of solid material/mineral wool
-
Chassis
Chassis in stainless steel
-
Pressure tank
Pressure tank with 4 bar test pressure
-
Insulating cladding
Insulating cladding made of highly polished stainless steel sheets, covering of the overlaps with stainless steel tensioning straps
-
Axle units
Various axle units up to 27 t total axle load, with disc brakes (EC system type approval), with EBS (Electronic Brake System and RSS (Roll Stability System) or RSP (Roll Stability Program), optional lift axle(s), steering axle
-
Various chamber sizes
Various chamber sizes and divisions, chamber subdivision with baffle walls in lightweight construction possible
-
Stainless steel tank contacts
All structural elements in contact with the tank under the insulation are made of stainless steel
-
Mudguard
Plastic single wheel mudguards or stainless steel mudguards
-
Tank material
Tank material CrNi (V2A) / CrNiMO (V4A), also in acid-resistant stainless steel quality or with rubber coating
-
Heating pipes
Heating pipes on the tank up to 4 bar for stationary operation with steam
-
Underride guard
Stainless steel/aluminum underride guard (EC system type approval)
-
Overflow boxes
Stainless steel overflow box/boxes and drain pipes
-
Heating on the move
Portable heating (operation with heating oil / diesel or gas) can be connected to the heating pipe
-
Support winches
2 support winches, load capacity 24 t
-
Compressed air/gas displacement line
Compressed air/gas displacement line in stainless steel with corresponding connections, safety valve and pressure gauge
-
Hose pipes
Stainless steel hose pipes
-
Catwalk
Walkway with folding aluminum safety railing, can be operated from below
In addition to the production of new vehicles, our vehicle construction department offers you a wide range of other services:
-
Vehicle acceptance
Acceptance of vehicles in accordance with the applicable legal regulations, hazardous goods vehicles with type approval
-
Repair of accident / vacuum and bodywork damage
on tankers and containers of all kinds
-
Insulation of tankers
Optionally with mineral fiber mats or solid insulation
-
Conversion work and technical vehicle equipment
of tankers for refrigerated liquefied gases
-
Installation of the electrical system
for tankers, also for gas vehicles
-
General overhaul of tankers
Conversion work to meet changed legal requirements
-
Paintwork and lettering
of all kinds
-
Preparation of tankers for the recurring pressure and leak tests
and demonstration for boiler acceptance by officially recognized experts
Our QM system
We install type-approved underride guards in accordance with UN Regulation 58. The quality management system in accordance with ISO 9001:2015 also takes into account the
requirements of international (ECE), European (EC) and German road traffic
and German road traffic law with regard to the approval object group 41 underride guard.
Certified vehicle construction
Klaeser also maintains a quality management system for welding manufacturers in accordance with ISO 3834-2 and is recognized as a manufacturer and repair company for the execution of welding work in accordance with ADR section 6.8.2.1.23.
TÜV NORD certificate
Certificate AD-2000 Leaflet HP-0 EN
Certificate TÜV NORD
English Version: Certificate AD-2000 Leaflet HP-0 EN
TÜV NORD certificate
Certificate in accordance with Directive 2014/86/EU Annex 1, No. 3.1 and DIN EN ISO 3834-2
Certificate TÜV NORD
English Version: Certificate according to Directive 2014/86/EU Annex 1, No. 3.1 and DIN EN ISO 3834-2
Customized solutions for vehicle construction
Contact by mail
Klaeser is also able to develop and implement individual solutions for special requirements. For example, Klaeser also manufactures special trailers for internal plant transportation. Contact us and we will work with you to find a solution and will be happy to provide you with a suitable quote. Our sales department will be happy to provide you with further information:
